Epson EB-L630U WUXGA 3LCD Laser Projector

Screen Size (Projected Distance):

Zoom : Wide:50″ – 500″ [1.44 – 14.76 m]Zoom : Tele:50” – 500” [2.35 – 23.84 m]

Geometric Correction:

Vertical/Horizontal Keystone:±30º / ±30ºProjection Orientation:360º Free

Operating Temperature:

Single Use:Low Altitude (0 – 2,286m/7,500ft): 0 – 45 °C <32 – 113 °F>
High Altitude (Over 2,286m/7,500ft to 3,048m/10,000ft): 0 – 40 °C <32 – 104 °F>
20% – 80% Humidity, No CondensationMulti-projection Use:Low Altitude (0 – 2,286m/7,500ft): 0 – 40 °C <32 – 104 °F>
High Altitude (Over 2,286m/7,500ft to 3,048m/10,000ft): 0 – 35 °C <32 – 95 °F>
20% – 80% Humidity, No Condensation

Operating Altitude:

Operating Altitude:Over 1,500m/4,921ft with High Altitude Mode: 0 – 3,048m (0 -10,000ft)

Start-Up Period:

Start-Up Period:8 sec (Epson Logo); Warm-up Period: 30 secQuick Start-Up:Less than 5 seconds (Display)

Cool Down Period:

Cool Down Period:Instant Off

Internal Speaker(s):

Sound Output:10W Monaural

Direct Power On/Off:

Direct Power On/Off:Yes

Weight:

Berat:Approx. 8.4kg

Air Filter:

Type:Electrostatic FilterMaintenance Cycle:20,000 hours (Normal) / 30,000 hours (Extended)

Fan Noise:

Fan Noise (Normal / Eco):38dB / 27dB

Dimension Excluding Feet:

Dimension Excluding Feet (D x W x H):304 x 440 x 122 mm

Brightness:

White Light Output (Normal / Extended):6,200lm / 4,340lmColour Light Output:6,200lmLight Output (Center):6,500lm*

Konektivitas:

Supported Speed for Each mode :Infrastructure:
IEEE 802.11b (2.4GHz): 11 Mbps*3
IEEE 802.11g (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 72.2 Mbps*3
IEEE 802.11a (5GHz): 54 Mbps*3
IEEE 802.11n (5GHz): 150.0 Mbps*3
IEEE 802.11ac (5GHz): 325Mbps*3

Access Point(Wi-Fi Direct):
IEEE 802.11g (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 72.2 Mbps*3
IEEE 802.11a (5GHz): 54 Mbps*3
IEEE 802.11n (5GHz): 150.0 Mbps*3
IEEE 802.11ac (5GHz): 325Mbps*3Supported Mode :Supported Mode: Infrastructure, Access Point(Wi-Fi Direct)Supported Security Type:Infrastructure:
OPEN, WPA2/WPA3-PSK
WPA2/WPA3-EAP

Supported EAP type:
PEAP, PEAP-TLS, EAP-TLS, EAP-Fast)

Access Point(Wi-Fi Direct):
WPA2-PSK(AES)

Konektivitas:

Supported Speed for Each mode :Access Point(Wi-Fi Direct):
IEEE 802.11g (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 72.2 Mbps*3
IEEE 802.11a (5GHz): 54 Mbps*3
IEEE 802.11n (5GHz): 150.0 Mbps*3
IEEE 802.11ac (5GHz): 325Mbps*3Supported Mode :Access Point (Wi-Fi Direct)Supported Security Type:Access Point (Wi-Fi Direct): WPA2-PSK (AES)

Specifications of Main Parts:

LCD:Size: 0.67″ (C2 Fine)
Resolution: WUXGA
Aspect Ratio: 16:10Light Source:Type: Laser Diode
Life*¹: 20,000 hours (Normal) / 30,000 hours (Extended)Projection Lens:Type: Optical Zoom (Manual) / Focus (Manual)
F-Number: 1.50 – 1.70
Focal Length: 20 – 31.8 mm
Zoom Ratio: 1.0 – 1.60
Throw Ratio: 1.35 – 2.20 (Wide – Tele)

Power Supply Voltage:

Power Supply Voltage:100 – 240 V AC ±10%, 50/60 Hz

Power Consumption (220 – 240V):

Laser Diode ON (Normal / Extended):345 W / 258WStand By:(Normal/Eco): 2.0W / 0.3W

Projectors Facets:

Features, Projectors Facets:Edge Blending
Screen Mirroring
WifiLaser / Lamp, Projectors Facets:LaserResolution, Projectors Facets:WUXGAContrast Ratio, Projectors Facets:5,000,000 : 1Inputs & Interfaces, Projectors Facets:RJ-45 & RS-232Brightness Range Lumens, Projectors Facets:4001
